Applied material: pebble, calcite, granite, quartz, concrete, dolomite, bluestone, iron ore, limestone, construction waste, etc.
Sand making machine is used in crushing and reshaping process of the medium hardness and extra hardness materials. In the engineering field, sand maker is the ideal production equipment of the mechanism sand, cushion material, asphalt concrete, and cement concrete aggregate. Suitable to more than 1000 materials, such as pebble, andesite, silica sand, limestone, quartz, basalt, calcite, concrete, iron ore, granite and river stone, etc. Output sand size is adjustable within 0-5mm, 5-10mm, 0-3mm, 0.5mm, etc.
As a new type of sand making machine, VSI sand crusher has 50% energy conservation than the traditional sand maker. The VSI sand making machine can make all kinds of rocks gravels and cobbles into construction sand with uniform particle size and high withstand voltage degree. Sands produced by the new type of sand making machine improve the construction quality and conform to the requirements of the building far more than natural sand and that produced by hammer type sanding machine and.
10-500 ton per hour for your choice. There is 30% production improvement of the VSI sand crusher.
The perfect crushing and impact angle, the proper material impact velocity design and the wear-resistant parts decrease the using costs and improve the benefits rates of this VSI sand crusher.
The six-side multi polygon size and reasonable grading make it suitable to mechanism sand and stone plastic. The comprehensive efficiency is improved by 30% according to the customers using guarantee and the comparison with same power machines.
Manufacturer features, equipment properties, equipment materials, equipment models and play important roles in the sand maker price.
We can customized sand making machine accoding to your mineral size, capacity and budget cost, which will save your costs and maximize your benefits. You are welcome to inquire by chatting with online service or leave your whatsapp/ email on our website. We will contact you within 24hours after receiving your inquiry.
Our sales team is available to respond to any queries you might have on Fote. Get in touch using the details below:
High and New Industrial Zone, Kexue Revenue, ZhengZhou, China.
| Model | Hard material | Soft material | Sand Shaping | Sand Making | Motor Power（kw） |
| Max.Feeding Size （mm） | Throughput（t/h） | ||||
| HVI 0815 | <30 | <35 | 50-140 | 90-230 | 2×75 |
| HVI 0818 | <30 | <35 | 60-190 | 110-283 | 2×90 |
| HVI 0922 | <35 | <40 | 70-210 | 150-330 | 2×110 |
| HVI 0926 | <35 | <40 | 85-240 | 170-380 | 2×132 |
| HVI 1032 | <40 | <45 | 130-278 | 180-400 | 2×160 |
| HVI 1040 | <40 | <45 | 180-284 | 250-440 | 2×200 |
| HVI 1263 | <50 | <55 | 320-498 | 370-585 | 2×315 |
| Model | Sand Shaping | Sand Making | Motor Power （kw） |
| Max.Feeding Size （mm） | |||
| HVI 0815 | 50-140 | 90-230 | 2×75 |
| HVI 0818 | 60-190 | 110-283 | 2×90 |
| HVI 0922 | 70-210 | 150-330 | 2×110 |
| HVI 0926 | 85-240 | 170-380 | 2×132 |
| HVI 1032 | 130-278 | 180-400 | 2×160 |
| HVI 1040 | 180-284 | 250-440 | 2×200 |
| HVI 1263 | 320-498 | 370-585 | 2×315 |
| Model | VSI 7611 | VSI 8518 | VSI 9526 | VSI 1140 | VSI 1145 | VSI 1150 | |
| Capacity (t/h) |
Feed both at center and sides | 80-180 | 140-260 | 200-380 | 300-520 | 350-610 | 360-650 |
| Feed at center | 40-90 | 70-130 | 100-190 | 160-260 | 180-355 | 190-365 | |
| Max.feeding size （mm） |
Soft material | 35 | 40 | 45 | 50 | 50 | 50 |
| Hard material | 30 | 35 | 40 | 40 | 45 | 45 | |
| Rotation speed（r/min） | 1700-1890 | 1520-1690 | 1360-1510 | 1150-1300 | 1150-1300 | 1150-1300 | |
| Motor power（kw） | 4P 110 | 4P 180 | 4P 264 | 4P 400 | 4P 440 | 4P 500 | |
| Overall dimension（L×W×H）（mm） | 4100×2250×2300 | 4160×2360×2500 | 4540×2500×2830 | 5500×2750×3100 | 5500×2750×3100 | 5500×2750×3100 | |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
| Model | Capacity(t/h) | |
| Feed both at center and sides | Feed at center | |
| VSI 7611 | 80-180 | 40-90 |
| VSI 8518 | 140-260 | 70-130 |
| VSI 9526 | 200-380 | 100-190 |
| VSI 1140 | 300-520 | 160-260 |
| VSI 1145 | 350-610 | 180-355 |
| VSI 1150 | 360-650 | 190-365 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
| Model specification |
Max.feeding size （mm） |
Power （kw） |
Rotation speed of impeller （r/min） |
Capacity （t/h） |
Overall dimension （L×W×H） （mm） |
| FTM-06 | 35 | 2P 37-55KW | 2000-3000 | 10-30 | 2500×1620×2600 |
| FTM-07 | 45 | 4P 55-75KW | 1500-2500 | 20-55 | 2700×1760×2800 |
| Model specification |
Capacity （t/h） |
| FTM-06 | 10-30 |
| FTM-07 | 20-55 |
FTM has equipment installed throughout the world in are as such as South Africa, Middle East, West Asia,India, Philippines, Western Europe, Southeastern Asia.
